Copper foil peel strength tester ASTRO-BLY60

Inspection Speed : Up to 2000 cm²/min

Resolution : 0.01 mm

Dimensions : 1200 mm x 800 mm x 1500 mm

Defect Types Detected : Missing components, misalignment, solder bridges, open circuits

Lighting System : LED multi-angle lighting

Power Supply : AC 110-240V, 50/60Hz

Place of Origin : Dongguan, Guangdong, China

Supported Pcb Size : 50 mm x 50 mm to 500 mm x 500 mm

Data Output : CSV, XML, and database integration

Detection Method : Automated Optical Inspection (AOI)

Weight : 150 kg

User Interface : Touchscreen LCD panel

Camera : High-resolution CCD camera

Component Types : SMD, Through-hole

Software : Real-time image processing with AI algorithms

Contact Now

Product highlights

The PST-R series copper foil peel strength tester is designed and manufactured in accordance with IPC-TM-650 Test Method Manual 2.4.8, it is specialized in measuring the peel strength of copper foil on rigid boards in the laboratories of the copper clad laminate and printed circuit board industries. Specification for PST-R series copper foil peel strength tester.

Scope of use

Scope of application: PCB copper foil tensile/peel strength test, professional used for measuring the peel strength of copper foil on rigid copper clad laminate, equipped with rigid sample fixture trolley.

Product description
  1. professional for measuring the peel strength of copper foil on the rigid copper clad laminate, equipped with Japanese rigid sample fixture trolley, quiet and smooth;
  2. force table ability: can choose 0-1 kg, 0-5 kg, 0-15 kg force table (optional) ;
  3. the force meter display unit can be converted between pounds, kilograms, Newtons;
  4. Accuracy: ± 0.20% (high load) ± (mantissa) ;
  5. the use of self-developed high-end tension meter software, the use of 4 and a half LCD digital display of the tension meter;
  6. with two-way RS232 interface, can be used with the computer connection, Great Wall 256G Solid State, motherboard asus H81 M-K, chassis + Great Wall 5000AD power supply, liquid crystal display, Win10 system;
  7. the force gauge built-in rechargeable battery;
  8. Stripping Speed: 50mm/min ± 5mm (2“/min)
  9. Stripping Stroke: 80mm
  10. Body size: 310 × 430 × 600mm (W × d × H)
  11. Weight: about 20kg
  12. Rated voltage: AC220V/50Hz, current: 3A
Working voltage AC220V/50Hz triangular power outlet, good ground connection required
Stripping speed 50 mm/min ± 5 mm (2“/min) stepless speed regulation
Ambient temperature 25 ± 3 °C
Ambient humidity 20-70% Rh
Schedule for divestiture 0-100mm
Pull-gauge capability 0-50N standard
Precision display 0.01 N
Dimensions (W × D × H)-310 × 430 × 600 mm
Measurement software Domestic high-end measurement software (optional)
Computer Memory: 1GB HARD DRIVE: 200gb (optional)
